Google VO Interview: UDP Out-of-Order Packet Reassembly — Sequencer Design (HashMap + seq pointer)

This Google VO question combines system design thinking with concrete implementation. It comes from real scenarios in log systems, stream processing pipelines, and distributed replication modules — all contexts where UDP's lack of ordering guarantees is a real challenge.

Problem Statement

UDP does not guarantee delivery order. An upstream sender continuously sends data fragments, each as (data, seq_num). Packets may arrive out of order, be duplicated, or be lost entirely.

Implement a Sequencer component on the receiver side that:

• Outputs data strictly in ascending seq_num order, with no gaps.
• If a middle sequence number has not arrived yet, buffer subsequent packets and wait until the gap is filled before outputting.

Approach

Core data structures: HashMap + next_seq pointer

• Use a dict to buffer received-but-not-yet-outputtable fragments: key = seq_num, value = data.
• Maintain a variable next_seq — the sequence number we expect to output next.

On receiving each new fragment:

1. Store (seq_num, data) in the buffer (deduplicate: ignore if already seen or already output).
2. Check if next_seq is in the buffer.
3. If yes: output it, remove from buffer, increment next_seq, repeat step 2.
4. If no: wait — do not output anything.

Why this works: HashMap gives O(1) lookup. Each packet is stored and retrieved exactly once. No sorting of the buffer is needed.

Code

class Sequencer:
    def __init__(self):
        self.buffer = {}      # seq_num -> data
        self.next_seq = 0     # next sequence number to output
        self.output = []      # ordered output so far

    def receive(self, seq_num: int, data: str):
        """Receive a data fragment."""
        # Deduplicate: ignore already-output or already-buffered
        if seq_num < self.next_seq or seq_num in self.buffer:
            return

        self.buffer[seq_num] = data

        # Flush as many in-order packets as possible
        while self.next_seq in self.buffer:
            self.output.append(self.buffer.pop(self.next_seq))
            self.next_seq += 1

    def get_output(self):
        return self.output

Dry Run

Arrival order: (2, "C") → (0, "A") → (1, "B") → (3, "D")

Final ordered output: A → B → C → D ✓

Complexity Analysis

• Time: O(1) per receive call (amortized) — each packet is stored once and flushed once.
• Space: O(k) where k is the number of out-of-order packets currently buffered (worst case O(n)).

Follow-up: Packet Loss Handling Strategies

The interviewer will likely ask: what if a seq_num never arrives?

Strategy 1: Timeout + Retransmission Request (ARQ)

Track how long we've been waiting for next_seq. If it exceeds a threshold, send a retransmission request (NACK) to the sender.

import time

class SequencerWithTimeout(Sequencer):
    def __init__(self, timeout=5.0):
        super().__init__()
        self.wait_start = None
        self.timeout = timeout

    def receive(self, seq_num, data):
        super().receive(seq_num, data)
        if self.next_seq not in self.buffer:
            if self.wait_start is None:
                self.wait_start = time.time()
        else:
            self.wait_start = None

    def check_timeout(self):
        """Returns seq_num to retransmit, or None."""
        if self.wait_start and time.time() - self.wait_start > self.timeout:
            return self.next_seq
        return None

Strategy 2: Skip and Forward

For latency-sensitive applications (live streaming, real-time audio/video), waiting is unacceptable. Skip the missing sequence number, insert a placeholder, and advance next_seq to the next available buffered packet.

def skip_missing(self):
    """Skip the missing seq and continue from next available."""
    if not self.buffer:
        return
    next_available = min(self.buffer.keys())
    self.output.append(None)  # placeholder for lost packet
    self.next_seq = next_available
    while self.next_seq in self.buffer:
        self.output.append(self.buffer.pop(self.next_seq))
        self.next_seq += 1

Strategy Comparison

Extended Discussion Points

• Duplicates: handled by if seq_num < self.next_seq or seq_num in self.buffer.
• Sliding window: add a maximum buffer size to prevent unbounded memory growth — analogous to TCP's receive window.
• Thread safety: in production, receive and check_timeout run on different threads — protect buffer and next_seq with a lock.
